1. Product Category: Toggle Switch
2. Model: R11-821T + Large Cover
3. Product Description: The R11-8T series is a new dustproof and waterproof toggle switch featuring an integrated dustproof structure. It offers extensive versatility and is widely used in various power tools, garden tools, and cleaning equipment such as table saws, bench grinders, electric lawn mowers, branch shredders, pressure washers, vacuum cleaners, etc. It is equally suitable for household appliances, instruments, and office equipment.
4. Safety Certification Technical Data: This product holds UL, TUV, S, KC, CE, and CQC certifications.
UL Certification Technical Parameters:
16(12)A 125/250VAC T125 5E4
16A 125/250VAC T125 5E4
16(14)A 125/250VAC T125 5E4
16A 125/250VAC T125 5E4
10A 36VDC T125 1E4
16/20/25A 36VDC T125 1E4
10/16/20A 48VDC T125 1E4
16(12)A 125/250VAC T125 5E4
TUV Certification Technical Parameters:
18(16)A 125VAC T125 5E4
16(16)A 125VAC T125 5E4
14(14)A 125VAC T125 5E4
10 / 16A 25VDC T125 5E4
10 A 25 / 36 / 48 VDC T125 5E4
16(16)A 125/250VAC T125 1E4
16(14)A 125/250VAC T125 5E4
16(12)A 125/250VAC T125 5E4
14(14)A 125/250VAC T125 5E4
12(12)A 125/250VAC T125 5E4
16(8)A 125/250VAC T125 5E4
16(14)A 125/250VAC T125 5E4 IP55
S Certification Technical Parameters:
16(8)A 250VAC T125 1E4
12(8)A 250VAC T125 5E4
16(8)A 250VAC T125 1E4
12(12)A 250VAC T125 5E4
16(8)A 250VAC T125 5E4
KC Certification Technical Parameters:
12(12)A 250VAC T125 5E4
CE Certification Technical Parameters:
16(8)A 250VAC T125 1E4
12(8)A 250VAC T125 5E4
CQC Certification Technical Parameters:
12(12)A 250VAC T125 5E4
16(12)A 250VAC T125/55 1E4
12(12)A 250VAC T125/55 1E4
16(8)A 250VAC T125/55 1E4
